Additive manufacturing Subtractive manufacturing

By forming or moulding materials into the desired shape with heat and/or
pressure, formative manufacturing processes such as injection moulding and

stamping produce objects. The purpose of formative techniques is to reduce the
marginal cost of producing individual parts; however, establishment costs are
exorbitant due to the need to create custom moulds or machinery for the
manufacturing process. With near-perfect repeatability and the ability to
manufacture components from a wide variety of materials (including metals and
plastics), these processes are nearly always the most cost-effective for mass

production.

In general, at the initial stage of the 3D printing process, a virtual model of the
potential object is created. This design will function as a guide for the 3D printer
to reproduce. Using computer-aided design (CAD) software, which can generate
precise drawings and technical illustrations, the virtual design is developed. A 3D

scanner, which basically takes photographs of an extant object from various
angles to copy it, may also be used to generate a virtual design. Once the virtual
model has been created, printing preparations must be undertaken. Slicing is the
process by which the target is accomplished; the model is divided into numerous

layers. During the slicing process, specialised software divides the model into
hundreds or even thousands of thin, horizontal layers.
